STEALTH SERIES

DF150A STEALTH

DF150A STEALTH

Suzuki Marine's new Stealth Line now offer more of the innovative technology and uncompromising power with sleek new matte black style.

More Power

With more torque (3.1% more for the DF150A and 2.7% more for the DF175A), as well as Suzuki’s proven offset driveshaft layout with 2-stage gear reduction, these new outboards generate more power throughout the full rpm range. Even on heavier, fully loaded boats, the DF150A and 175A take performance to the next level.

Quick Acceleration

The DF150A and DF175A now share the same engine block used for our popular DF200A. Big displacement and precise mechanical design combine for quicker acceleration, whether out of the hole or in mid-range. We’re satisfying our customers’ desire for performance and improved fuel economy.

Fuel Efficient

With a combination of our Lean Burn technology, a semi-direct intake system and a high performance compression ratio of 10.2-to-1, these new outboards deliver clean, efficient power. Compared to the previous generation, the DF175A is 14% more fuel efficient and the DF150A shows a 7% improvement for significant savings at the fuel dock.

DURABILITY & RELIABILITY
  • Self-adjusting Timing Chain
  • Suzuki Anti-corrosion Finish
  • Suzuki Water Detecting System
  • Tilt Limit System
PERFORMANCE
  • Offset Driveshaft / 2 Stage Gear Reduction
  • VVT (Variable Valve Timing)
  • 2-stage Gear Reduction
EASE & COMFORT
  • Suzuki Selective Rotation
  • Quiet Operation
  • Suzuki Troll Mode System
ECOLOGY & ECONOMY
  • Lean Burn

MODEL DF150AS
RECOMMENDED TRANSOM HEIGHT mm (in.) L: 508, X: 635
STARTING SYSTEM Electric
WEIGHT kg *1 L: 235, X: 240
ENGINE TYPE DOHC 16-Valve
FUEL DELIVERY SYSTEM Electronic Fuel Injection
NO. OF CYLINDERS 4
PISTON DISPLACEMENT cm3 (cu.in.) 2867
BORE × STROKE mm (in.) 97 x 97
MAXIMUM OUTPUT kW (PS) 110.3
FULL THROTTLE OPERATING RANGE rpm 5,000-6,000
STEERING Remote
OIL PAN CAPACITY Lit. 8.0
ALTERNATOR 12V 44A
ENGINE MOUNTING Shear Mount
TRIM METHOD Power Trim and Tilt
GEAR RATIO 2.50:1
GEAR SHIFT F-N-R
PROPELLER SELECTION (Pitch)*2 All propellers are the 3-blade type 17-30
CONTROL SYSTEM Mechanical
  1. Dry weight: not including propeller and engine oil
  2. Please inquire at your local dealer for details of the propeller
  3. Counter Rotation Model Available

The appearance, colors, and equipment of outboard motors may differ according to market and grade.
Specifications may change without prior notice.
*Manufacture data
